Hikvision DS-2AE4215TI-D(C) 2MP IR Turbo 4-Inch Speed Dome

Hikvision DS-2AE4215TI-D(C) 2MP IR Turbo 4-Inch Speed Dome Camera

The Hikvision DS-2AE4215TI-D(C) represents a robust surveillance solution designed for comprehensive security monitoring. This 4-inch speed dome camera combines advanced optical technology with intelligent tracking capabilities to deliver precise and reliable video surveillance.

Optical Performance and Imaging

The DS-2AE4215TI-D(C) boasts a powerful 2-megapixel sensor that captures crisp, clear images with exceptional detail. Moreover, its advanced imaging capabilities ensure superior performance in various lighting conditions. Consequently, users can rely on consistent video quality regardless of environmental challenges.

Intelligent Tracking and Movement

Equipped with high-speed pan-tilt-zoom (PTZ) functionality, the Hikvision DS-2AE4215TI-D(C) can rotate 360 degrees horizontally and tilt 90 degrees vertically. This extensive range of motion allows for comprehensive area coverage and rapid subject tracking. Furthermore, the camera’s intelligent tracking algorithms enable automatic subject detection and following.

Ideal Users and Application Scenarios

The Hikvision DS-2AE4215TI-D(C) is perfectly suited for:

• Security Professionals: Requiring comprehensive surveillance with minimal blind spots
• Large Facility Managers: Needing wide-area monitoring in industrial parks, warehouses, and campuses
• Municipal Security Teams: Monitoring public spaces with dynamic tracking capabilities
• Transportation Hubs: Requiring flexible and responsive surveillance systems

Key Advantages

• Precise 15x optical zoom for detailed long-distance monitoring
• Robust infrared (IR) capabilities with up to 100 meters of night vision range
• Weather-resistant design supporting challenging environmental conditions
• Low-light performance with advanced WDR (Wide Dynamic Range) technology

Technical Specifications

Sensor Specifications

• Sensor Type: 2MP CMOS
• Effective Pixels: 1920 × 1080
• Minimum Illumination: Color: 0.01 Lux, B/W: 0.001 Lux

Optical Characteristics

• Focal Length: 5-75mm
• Optical Zoom: 15x
• Digital Zoom: 16x
• Lens Mount: Built-in Varifocal Lens

Performance Metrics

• Frame Rate: 25/30 fps @ 1080P
• Video Compression: H.264+/H.265+
• Smart Features: Motion Detection, Intrusion Detection, Line Crossing Detection

Mechanical Specifications

• Pan/Tilt Range: Pan 360°, Tilt 90°
• Pan/Tilt Speed: Pan 0.1°-240°/s, Tilt 0.1°-100°/s
• Preset Speed: 240°/s

Environmental Ratings

• Operating Temperature: -30°C to +60°C
• Protection Rating: IP66
• Power Input: DC12V/AC24V

Connectivity

• Network Interface: RJ45 10M/100M Ethernet
• Protocols: TCP/IP, HTTP, HTTPS, SSL, TCP, UDP, ICMP, IGMP, SMTP, FTP, DDNS, NTP, RTSP, RTCP, RTP, SIP, QoS

Physical Characteristics

• Dimensions: 159 × 159 × 362 mm
• Weight: Approximately 1.8 kg
• Material: Aluminum Alloy

The Hikvision DS-2AE4215TI-D(C) stands as a testament to advanced surveillance technology, offering comprehensive monitoring capabilities for diverse security requirements.
