Hikvision DS-2AE4225TI-D PTZ Camera: Advanced Surveillance Precision

The Hikvision DS-2AE4225TI-D represents a powerful solution in surveillance technology, combining cutting-edge optical performance with robust engineering. Moreover, this PTZ (Pan-Tilt-Zoom) camera delivers exceptional visual intelligence for comprehensive security monitoring.

Optical Excellence and Performance

The DS-2AE4225TI-D boasts a remarkable 25x optical zoom capability, enabling users to capture intricate details from considerable distances. Consequently, this feature allows for precise monitoring of expansive areas with remarkable clarity. Additionally, the 2-megapixel sensor ensures crisp, high-resolution imagery that captures critical visual information.

Key Technological Advantages

• Advanced Zoom Mechanism: The 25x optical zoom provides unprecedented visual reach
• Infrared Capabilities: Integrated IR technology supports night vision up to 150 meters
• Intelligent Tracking: Sophisticated motion tracking ensures continuous subject monitoring
• Weather-Resistant Design: Engineered to withstand challenging environmental conditions

Ideal Users and Application Scenarios

The Hikvision DS-2AE4225TI-D is optimally suited for:

• Large Perimeter Security: Organizations requiring extensive surveillance coverage
  • Reason: 25x zoom and 150m IR range enable comprehensive area monitoring
• Critical Infrastructure Protection: Facilities needing detailed visual intelligence
  • Reason: High-resolution 2MP sensor captures precise details
• Industrial Complexes: Environments demanding robust, long-range monitoring
  • Reason: Durability and advanced optical performance meet rigorous industrial standards
• Transportation Hubs: Airports, seaports, and large transit centers
  • Reason: PTZ functionality allows dynamic, real-time tracking of moving subjects

Technical Specifications

Imaging Specifications

• Sensor Type: 2.0 Megapixel CMOS
• Resolution: 1920 × 1080
• Frame Rate: 25/30 fps at full resolution

Optical Specifications

• Optical Zoom: 25x
• Focal Length: 4.8-120mm
• Horizontal Field of View: 62.4°-2.5°
• Vertical Field of View: 36.8°-1.4°

Mechanical Specifications

• Pan Range: 360° continuous
• Tilt Range: -15° to 90°
• Preset Positions: 256
• Scanning Speeds: Pan: 0.1°-300°/s, Tilt: 0.1°-100°/s

Performance Specifications

• Minimum Illumination: Color: 0.005 Lux, B/W: 0.0005 Lux
• Signal-to-Noise Ratio: >56 dB
• Day/Night Function: Automatic IR-cut filter

Environmental Specifications

• Operating Temperature: -40°C to +65°C
• Protection Rating: IP66
• Humidity: ≤95% (non-condensing)

Connectivity

• Video Output: Analog HD
• Transmission Distance: Up to 1200m
• Power Supply: 24V AC/DC

Final Insights

The Hikvision DS-2AE4225TI-D transcends traditional surveillance solutions by offering intelligent, adaptable monitoring capabilities. Furthermore, its robust engineering ensures reliable performance across diverse environmental challenges.
