Hikvision DS-K4SL500MKW Smart Lock

Key Features and Capabilities

Versatile Authentication Methods

The DS-K1T502DBFWX-C offers multiple authentication options to ensure secure access:

• Fingerprint recognition with a capacitive module
• Card-based authentication (M1 and DESfire card support)
• PIN code entry
• Multi-factor authentication for enhanced security

Network Connectivity and Integration

Designed for modern security infrastructure, the terminal provides:

• Wired and wireless network support (RJ-45 and 2.4G Wi-Fi)
• Bluetooth connectivity for smartphone-based access
• Supports multiple network protocols (IPV4 and IPV6)
• Seamless integration with SIP servers and access control systems

Ideal Users

This access control terminal is perfect for:

• Corporate offices requiring robust security management
• Educational institutions seeking multi-layered access control
• Healthcare facilities needing strict entry monitoring
• Government buildings with high-security requirements
• Industrial complexes with complex access needs

The DS-K1T502DBFWX-C is particularly suitable for organizations that:

• Require diverse authentication methods
• Need remote management capabilities
• Prioritize scalable and flexible security solutions

Technical Strengths

Moreover, the device offers impressive technical capabilities:

• Large storage capacity (10,000 fingerprints, 100,000 cards)
• Quick card reading (less than 1 second)
• Extensive event logging (300,000 event capacity)
• Wide operating temperature range (-40°C to 70°C)

Environmental Durability

Constructed with durability in mind, the DS-K1T502DBFWX-C features:

• IP65 and IK09 protection levels
• Zinc alloy materials for increased stability
• White and infrared supplemental lighting
• Compact design (81mm x 177mm)

Additional Functionality

The terminal supports:

• Video intercom
• Two-way audio communication
• Live view capabilities
• Hik-Connect mobile app integration
• Multiple language options

Optional Accessories

• DS-KAB502-S1: Protective Shield
• DS-KAB502-S2: Wall Mounting Box

Specifications

System

• Operating System: Linux
• ROM: 4 GB
• RAM: 256 MB
• CPU: 960 MHz

Video

• Resolution: 2 MP
• Field of View:
  • Horizontal: 110°
  • Vertical: 81°
  • Diagonal: 122°
• Video Compression: H.264 and H.265

Power and Environment

• Power Supply: 12-24 VDC
• Power Consumption: ≤ 12 W
• Working Temperature: -40°C to 70°C

Network Interfaces

• 1x RJ-45 10/100 Mbps self-adaptive
• Wi-Fi (2.4G, 802.11b/g/n)
• Bluetooth (2.1/4.2)

Authentication Capabilities

• Fingerprint Capacity: 10,000
• Card Capacity: 100,000
• Event Capacity: 300,000
